Aimgain GTM-X

Aimgain GTM-X - 20 and 22-Inch 2-Piece Mesh Wheel for 4WD and SUV Platforms

6/139.7 PCD Mesh Wheel with Reverse Rim, Hyper Black to Matte Bronze

Aimgain GTM-X is a 2-piece mesh wheel available in 20 and 22 inches with PCD 6/139.7, designed for Toyota Land Cruiser 300, Toyota Tundra, Lexus LX600, and other 6-bolt SUV and truck platforms. The GTM-X applies Aimgain's two-piece construction technology to large-format 4WD vehicles, combining a cast aluminum mesh disc with an alumite rim in a reverse rim configuration at all sizes. Custom disc colour, rim colour, and centre cap combinations are available across the full size range.

Aimgain GTM-X Design and Engineering: 2-Piece Mesh for 6-Bolt SUV Platforms

The GTM-X mesh disc features the same angular spoke pattern as the GTM series, scaled for the bolt face and offset requirements of Toyota and Lexus SUV chassis. All sizes use a reverse rim to achieve the deep barrel necessary for stance builds on Land Cruiser and Tundra. Disc colours include standard finishes Black, Semi Gloss Black, Matte Black, Matte Gunmeta, and Matte Bronze through premium Hyper Silver and Hyper Black. Rim options cover Buff Alumite, Cut Alumite, Black Alumite, Black Cut Alumite, Matte Black Alumite, Brushed, Bronze Alumite, and Matte Bronze Alumite. Centre caps are 70mm diameter acrylic type in six colour combinations. Pierce bolts in Chrome, Gold, and Black. JWL/VIA certified. TPMS drilling available at order.

Aimgain GTM-X Technical Specifications

Construction: 2-piece cast aluminum alloy disc with alumite rim. Certification: JWL, VIA. Available diameters: 20 and 22 inches. Rim configuration: reverse rim at all sizes. PCD: 6/139.7. Hub bore: 106.1mm. Available widths: 8.5J to 12.5J depending on diameter. Contact Hodoor Wheels for the full inset table and current pricing.

Aimgain GTM-X Available Finishes

Standard disc colors: Black (BK), Black Metallic (BKM), Semi Gloss Black (HMB), Matte Black (MB), White (WH), Gold (GD), Matte Gunmeta (MG), Matte Bronze (MBZ). Premium disc colors: Hyper Silver (HS) and Hyper Black (HB). Option colors: White Nova Pearl (NW), Candy Gold (CGD), Hyper Red Clear (HRC), Eternal Blue Pearl (EB). Special finish: Super Black Chrome (SBC). Rim finishes: Buff Alumite (D), Cut Alumite (F), Black Alumite (KL), Black Cut Alumite (FK), Matte Black Alumite (KK), Brushed (H), Bronze Alumite (GL), Bronze Cut Alumite (FG), Matte Bronze Alumite (GG). Contact Hodoor Wheels for the complete finish catalogue.

Aimgain GTM-X Vehicle Fitment: Toyota Land Cruiser 300, Tundra, Lexus LX600

Documented fitment at 22x10.0J inset 55 Low Disk (PCD 6/139.7) for Toyota Land Cruiser 300 and Lexus LX600 in Hyper Black with Black Alumite rim. Standard stance fitment at 22x9.5J inset 50 for most 6/139.7 platforms. Wide body fitment at 22x11.0J inset -4 and 20x9.5J inset 20 Low Disk for Toyota Tundra and Sequoia. Matte Bronze and Matte Gunmeta configurations at 20-inch target outdoor-oriented builds on Prado and Tundra. Contact Hodoor Wheels with your vehicle specification to confirm fitment.

Aimgain GTM-X - Any Vehicle, Any Specification

The GTM-X is available in 20 and 22 inches for PCD 6/139.7 platforms. Contact Hodoor Wheels at [email protected] or via WhatsApp to confirm fitment for your specific vehicle and place an order. JWL/VIA certification is maintained across all available configurations.
